Electrical insulating paper Nomex® made of meta-aramid

Nomex® electrical paper of DuPont is based on the extremely heat-resistant material meta-aramid, which is particularly well known for its use in protective clothing. The outstanding properties of this material also make it extremely attractive for the electrical industry. As a highly valued insulating material, it is used in electric motors and transformers in the electrical industry, among other things.

Find your right Nomex® electrical insulating paper!

You have questions according to our Nomex® products or want to send an inquiry?
Our sales representative will be happy to help you.

Excellent insulating properties of Nomex® electrical insulating papers

Nomex® electrical insulating papers in our range belong to insulating class H (180 °C). They are extremely heat-resistant and flame-retardant in accordance with UL 94V-0. Its high resistance to chemicals makes the meta-aramid compatible with all classes of standard resins, varnishes, adhesives, transformer fluids, lubricating oils and coolants. This means you can use the electrical insulating paper in a large number of applications.

You will find the following products in our range:

Advantages of Nomex®

  • Rated insulation class H (180 °C)
  • Can be used at ultra-low temperatures of -190 °C
  • UL-listed (E34739)
  • Flame retardant according to UL 94 V-0
  • Self-extinguishing
  • Very high beta and gamma radiation resistance
  • High short-time dielectric strength
  • Very good dielectric strength
  • Resistant to solvents, acids and alkalis

Our processing options for Nomex® electrical insulating papers – cutting, punching, gluing

As a leading provider of electrical insulation solutions, we offer you comprehensive processing options for your Nomex® electrical insulating paper.

Nomex® electrical insulating paper is available on roll as standard or as customized cut. Also available are Nomex® adhesive tapes in various versions.

To improve the properties of the insulating papers, we have specialized in the production of laminates. Combine the Nomex® products with another insulating material and thus combine the positive properties. We already have standard material combinations available on the market. Do you need a customized combination? Contact our product manager and plan your customized insulation material with him.

We also offer you the option of processing the material into customized punched or bent parts. The experts from our plant in Schramberg are available to help you plan your product - from the initial idea to the finished stamped part.

Our electrical insulating papers SynTherm® YT510 and SynTherm® YT56

Discover the smart Nomex® alternatives of SynFlex

We offer smart and cost-effective alternatives to the existing Nomex® products. Our electrical insulating papers SynTherm® YT510 and SynTherm® YT56 made of meta-aramid also have excellent thermal and mechanical properties and at the same time have significantly better oil absorption than the branded product.

Additionally, SynTherm® YT510 and SynTherm® YT56 have individual and also system approvals by UL, just like Nomex® 410 and Nomex® E56. Our SynLab® test laboratory and our UL experts are at your disposal for consultation on the topic of tests and approvals.

Discover our smart alternatives
